| PART |
Description |
Maker |
| PMB2331 |
The mixer used in this design is a general purpose up-/downconversion gilbert cell mixer
|
SIEMENS AG
|
| MMBD354LT1 |
Dual Hot Carrier Mixer Diodes(双热载流子混频器二极 SILICON, UHF BAND, MIXER DIODE, TO-236AB
|
ON Semiconductor
|
| Q62702-F1582 BF569W Q62702-F1322 |
From old datasheet system
PNP Silicon RF Transistor (For oscillators mixer and self-oscillating mixer stages in UHF TV-tuner)
PNP Silicon RF Transistor kein Status
PNP Silicon RF Transistor (For oscillators, mixer and self-oscillating mixer stages in UHF TV-tuner)
NPN Silicon RF Transistor (For low-distortion broadband output amplifier stages in antenna and telecommunications) NPN硅射频晶体管（低失真输出天线的宽带和电信放大级）
|
Siemens Semiconductor G...
SIEMENS[Siemens Semiconductor Group]
Infineon
SIEMENS AG
|
| LAVI-17VH |
Frequency Mixer 470 MHz - 1730 MHz RF/MICROWAVE DOUBLE BALANCED MIXER, 8.9 dB CONVERSION LOSS-MAX
|
Mini-Circuits
|
| MCA-35LH |
Frequency Mixer WIDE BAND 500 MHz - 3500 MHz RF/MICROWAVE TRIPLE BALANCED MIXER, 8.9 dB CONVERSION LOSS-MAX
|
Mini-Circuits
|
| HMC215LP411 HMC215LP4E |
GaAs MMIC MIXER w/ INTEGRATED LO AMPLIFIER, 1.7 - 4.0 GHz
1700 MHz - 4000 MHz RF/MICROWAVE DOUBLE BALANCED MIXER, 11 dB CONVERSION LOSS-MAX
|
Hittite Microwave Corporation
|
| XM1001-QH-0G0T XM1001-QH-0G00 XM1001-QH-EV1 |
10.0-34.0 GHz Image Reject Mixer QFN, 4x4 mm 10000 MHz - 33000 MHz RF/MICROWAVE IMAGE REJECTION MIXER
10.0-34.0 GHz Image Reject Mixer QFN, 4x4 mm 10.0-34.0 GHz的图像抑制混频器QFN封装 × 4
|
Mimix Broadband, Inc.
|
| BA128210 BA1283-TR3 |
Band Switching Diodes
DIODE SILICON, VHF BAND, MIXER DIODE, HALOGEN FREE AND ROHS COMPLIANT, HERMETIC SEALED, GLASS, MICROMELF-2, Microwave Mixer Diode
|
Vishay Siliconix
Vishay Semiconductors
|
| ESMD-C3 ESMD-C3TR |
20 MHz - 2500 MHz RF/MICROWAVE DOUBLE BALANCED MIXER, 10.5 dB CONVERSION LOSS-MAX
E-Series Surface Mount Mixer 20 - 2500 MHz
|
MACOM[Tyco Electronics]
|
| SGD-100 |
C to X Band/ Mixer/ Modulator Applications
GaAs Schottky Barrier Diode（C to X Band, Mixer, Modulator Applications应用于C到X带宽，混频器和调制器的砷化镓肖特基势垒二极管) 砷化镓肖特基二极管（C到X波段，搅拌机，调制器应用）（应用于荤到X带宽，混频器和调制器的砷化镓肖特基势垒二极管
|
SANYO[Sanyo Semicon Device]
Sanyo Electric Co.,Ltd.
Sanyo Electric Co., Ltd.
|
| ADL5802 ADL5802-EVALZ ADL5802ACPZ-R7 ADL580209 |
Dual Channel, High IP3, 100 MHz to 6 GHz Active Mixer
Dual Channel High IP3 100 MHz – 6 GHz Active Mixer; No of Pins: 24 100 MHz - 6000 MHz RF/MICROWAVE DOUBLE BALANCED MIXER
|
Analog Devices, Inc.
|
| TOP-2MZ TOP-5MZ TOP-1MZ CMF-102 CMP-312 CMP-302 CM |
50 MHz - 1000 MHz RF/MICROWAVE DOUBLE BALANCED MIXER, 9 dB CONVERSION LOSS-MAX
20 MHz - 1500 MHz RF/MICROWAVE DOUBLE BALANCED MIXER, 9 dB CONVERSION LOSS-MAX
2 MHz - 600 MHz RF/MICROWAVE DOUBLE BALANCED MIXER, 8 dB CONVERSION LOSS-MAX
0.01 MHz - 125 MHz RF/MICROWAVE DOUBLE BALANCED MIXER, 6.5 dB CONVERSION LOSS-MAX
0.025 MHz - 200 MHz RF/MICROWAVE DOUBLE BALANCED MIXER, 7 dB CONVERSION LOSS-MAX
0.1 MHz - 500 MHz RF/MICROWAVE DOUBLE BALANCED MIXER, 8 dB CONVERSION LOSS-MAX
10 MHz - 1000 MHz RF/MICROWAVE DOUBLE BALANCED MIXER, 9.5 dB CONVERSION LOSS-MAX
|
Synergy Microwave, Corp.
SYNERGY MICROWAVE CORP
|
